Bars & Forgings For Oil & Gas Industry
Click any of our material grades below for further detail and size availability.
| Our Grade | Equivalent Standard | |
| AISI 4130 NACE | AISI 4130 | |
| AISI 4140 Non-NACE | AISI 4140 | |
| AISI 4140 NACE | AISI 4140 | |
| AISI 4340 NACE | AISI 4340 | |
| AISI 8630 Mod NACE | AISI 8630 modified | |
| AISI 410 NACE | UNS S41000 | |
| 17-4 PH NACE | UNS S17400 | |
| Alloy K500 NACE | UNS N05500 | |
| Alloy 718 NACE | UNS N07718 | |
| AISI 4130 (NACE) | |
|
Typical Analysis, %
|
C 0.28-0.33, Si 0.15-0.35, Mn 0.40-0.60, Cr 0.80-1.10 |
| Mo 0.15-0.25, V 0.05 max, S 0.025 max, P 0.025 max | |
| Supplied Condition | Normalised, hardened and tempered. |
| Typical Hardness | 207-235 BHN |
|
Stock Range
|
Round: 25 – 920mm |
| Square: 260 – 485mm | |
| AISI 4140 (Non-NACE) | |
|
Typical Analysis, %
|
C 0.38-0.43, Si 0.15-0.35, Mn 0.75-1.00, Cr 0.80-1.10, Mo 0.15-0.25 |
| S 0.025 max, P 0.025 max | |
| Supplied Condition | Normalised, hardened and tempered. |
| Typical Hardness | 277-302 BHN |
| Stock Range | Round: 36 – 690mm |
| AISI 4140 (NACE) | |
|
Typical Analysis, %
|
C 0.38-0.43, Si 0.15-0.35, Mn 0.75-1.00, Cr 0.80-1.10, Mo 0.15-0.25 |
| Ni 0.25 max, V 0.30 max, S 0.025 max, P 0.025 max, Cu 0.35 max | |
| Supplied Condition | Normalised, hardened and tempered. |
| Typical Hardness | 207-235 BHN |
| Stock Range | Round: 50 – 450mm |
| AISI 4340 (NACE) | |
|
Typical Analysis, %
|
C 0.38-0.43, Si 0.15-0.35, Mn 0.60-0.80, Cr 0.70-0.90, Mo 0.20-0.30 |
| Ni 1.65-2.00, S 0.040 max, P 0.035 max | |
| Supplied Condition | Hardened and tempered. |
| Typical Hardness | 207-235 BHN |
| Stock Range | Round: 16 – 400mm |
| AISI 8630 Mod (NACE) | |
|
Typical Analysis, %
|
C 0.28-0.33, Si 0.15-0.35, Mn 0.75-0.95, Cr 0.80-1.00, Mo 0.35-0.45 |
| Ni 0.70-0.90, S 0.025 max, P 0.025 max | |
| Supplied Condition | Hardened and tempered. |
| Typical Hardness | 217-235 BHN |
| Stock Range | Round: 360 – 850mm |
| AISI 410 Stainless (NACE) | |
|
Typical Analysis, %
|
C 0.07-0.15, Si 1.00 max, Mn 1.00 max, Cr 11.50-13.50, Mo 0.50 max |
| Ni 0.40 max, S 0.025 max, P 1.025 max | |
| Supplied Condition | Hardened and double tempered. |
| Typical Hardness | 207-235 BHN |
|
Stock Range
|
Round: 32 – 692mm |
| Square: 225 – 465mm | |
| 17-4 PH (Stainless) (NACE) | |
|
Typical Analysis, %
|
C 0.07 max, Si 1.00 max, Mn 1.00 max, Cr 15.50-17.50, Ni 3.00-5.00 |
| S 0.03 max, P 0.05.max, Cu 3.00-5.00, Cb+Ta 0.15-0.45 | |
| Supplied Condition | Solution annealed an double aged (2 x H1150). |
| Typical Hardness | 279-311 BHN |
| Stock Range | Round: 30 – 300mm |
| Alloy K500 (NACE) | |
|
Typical Analysis, %
|
C 0.25 max, Si 0.50 max, Mn 1.50 max, Ni 63.0-70.0, S 0.01 max |
| Al 2.30-3.15, Fe 2.00 max, Cu 27.00-33.00, Ti 0.35-0.85 | |
| Supplied Condition | Hot finished (worked), solution annealed and age hardened. |
| Typical Hardness | 255-321 BHN |
| Stock Range | Round: 32 – 45mm |
| Alloy 718 (NACE) | |
|
Typical Analysis, %
|
C 0.08 max, Si 0.35 max, Mn 0.35 max, Cr 17.00-21.00, Mo 2.80-3.30 |
| Ni+Co 50.00-55.00 S 0.015 max, P 0.015 max, Al 0.20-0.80, Cu 0.30 max | |
| Ti 0.65-1.15, Cb+Ta 4.75-5.50, Co 1.00 max, B 0.006 max, Fe Bal. | |
| Supplied Condition | Solution annealed and age hardened. |
| Typical Hardness | 298-362 BHN |
| Stock Range | Round: 32 – 110mm |
